DR Manual-Start - Push User Manual

48 DR
®
WALK-BEHIND LEAF & LAWN VACUUM
Parts List - Drive/Rear Axle Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
80 21825 Bracket, Transmission Mount
81 21809 Bearing, 3/4" w/Pillow Block
82 21386 Differential, 54 Tooth D-Cut
83 21824 Bracket, Trans., Anti Rotation
84 21840 Guard, Drive
85 21917 Trans., 3-Speed
86 21912 Sprocket, 8 Tooth
87 21789 Belt, 3L34
88 21808 Bearing, 1/2" Clip
89 21882 Plate, Trans., Bearing Mount
90 21943 Washer, Lock, Internal Tooth, 1/2"
91 21894 Screw, Socket Head, 1/4"-20 x 3/4"
92 21928 Washer, 5/16" Lock, Twisted Tooth
93 21935 Wheel, 14" Assembly Drive
94 21811 Bolt, Carriage 1/4"-20 x 1"
95 21826 Bracket, Trans., Reinforce
96 21830 Bolt, Carriage 3/8"-20 x 1-1/2"
97 21855 Pulley, Idler, 2" OD x 3/8" ID
98 21918 Tube, 3/4" ID, Wheel Spacer
99 21932 Washer, 1/4" Lock, Twisted Tooth
100 21924 Washer, 1/4", SAE, ZP
101 21872 Nut, Lock, Nylon Insert, 1/4"-20
102 21905 Screw, Cap, 5/16"-18 x 3-1/2", HCS, ZP
103 21875 Nut, Lock, Nylon Insert, 5/16"-18
104 21904 Screw, Cap, 5/16"-18 x 3/4", ZP
105 21926 Washer, 3/8", SAE, ZP
106 21804 Bolt, 1/4"-20 x 5/8", HWH
Ref# Part# Description
107 21893 Screw, Self-Tap, 5/16"NC x 3/4" Hex
108 21831 Chain, #41 x 42 Pitch
109 21911 Spring, Tension
110 21923 Washer, 1/4", FC, ZP
111 21925 Washer, 3/4", SAE
112 21937 Key, Woodruff, 1/8" x 1/2"
113 21832 Clip, 1/2"
114 21834 Control, Shift, Wescon
115 21833 Control Lever Assy, Clutch
116 21930 Washer, Flat, 1/2", SAE
117 21898 Screw, Cap, 1/4"-20 x 4", HCS, ZP
118 21855 Label, Danger, Guard
119 21868 Nut, Lock, 3/8"-16, LT. WT. Thin, ZP
120 21853 Label, Clutch Drive
121 21816 Bracket, Bearing
122 21820 Screw, Cap, 5/16"-18 x 3", HCS, ZP
The following are applicable to the Push model only:
200 21930 Washer, Flat, 1/2", SAE
201 21812 Bolt, Carriage, 5/16"-18 x 2-1/2"
202 21923 Washer, 1/4", FC, ZP
203 21875 Nut, Lock, Nylon Insert, 5/16"-18, UNC
204 21871 Nut, Lock, Nylon Insert, 1/2"-13 UNC
205 21908 Shaft, Rear Axle
206 21821 Bracket, Mount, Rear Axle
207 21936 Wheel, 14", w/Bearing and Tire
