46 DR
®
WALK-BEHIND LEAF & LAWN VACUUM
CHAPTER 7
PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY
Parts List - Nozzle and Front Axle Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 21938 Yoke 1/2"-20
02 21877 Pin, Yoke 1/2"
03 21830 Bolt, Carriage, 3/8"-16 x 1-1/2", ZP
04 21926 Washer, Flat, 3/8", SAE, ZP
05 21868 Nut, Lock, Nylon, 3/8"-16, Thin, ZP
06 21902 Screw, Cap, 5/16"-18 x 3-1/2"
07 21875 Nut, Lock, Nylon, 5/16"-18, UNC
08 21931 Washer, Flat, Fender, 5/16"
09 21871 Nut, Lock, Nylon, 1/2"-13, UNC Thin
10 21932 Washer, 1/4", FC, ZP
11 21862 Label, Warning, Open
12 21813 Bolt, Carriage, 5/16"-18 x 3-1/2"
13 21890 Roll Pin, 1/4" x 1" long
14 21930 Washer, 1/2", SAE
15 21864 Nozzle, Vacuum, 27", Plastic
16 21829 Cap, 5", Vacuum Hose
17 21824 Handle, Lower, Vacuum
18 21936 Wheel, 14", Assy w/Bearing & Tire
19 21805 Axle, Front
20 21817 Bracket, Height
Ref# Part# Description
21 21803 Bolt, 1/4"-20 x 3/4", HWH
22 21863 Link, Height Adjuster
23 21820 Bracket, Nozzle, Wear Guard
24 21886 Rod, Connect, Height Adjuster
25 21827 Bushing, 0.5" ID x 0.625" OD x 0.250"
26 21888 Rod, Handle, Crank
27 21841 Handle, Crank, 0.5" ID x 3.72" Long
28 21828 Bushing, 3/8" ID x 1/2" OD x 3/8" long
29 21932 Washer, Lock, Twisted Tooth, 1/4"
30 21869 Nut, Pal, 1/2" Diameter
31 21865 Cover, Nozzle
32 21181 Label, Product Decal, DR
33 21892 Screw, Plastic
34 21875 Label, Height Adjuster
35 21893 Screw, Self-Tap, 5/16", NC x 3/4" Hex
36 21818 Bracket, Nozzle, Cover Reinforcement
37 21811 Bolt, Carriage, 1/4"-20 x 3/4"
38 21867 Nut, Flange, 1/4"-20
