DR SCOUT User Manual

38 DR
®
SCOUT

FIELD and BRUSH MOWER
Parts List - Frame and Drive Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 165341 Frame, Main, w/Engine Plate
02 174641 Engine, 7.0 HP, B&S
03 111591 Bolt, 5/16"-18 x 2-1/2" HCS
04 110761 Nut, Nylon Lock, 5/16"-18
05 150451 Bolt, 5/16"-18 x 1-3/4" HCS
06 112501 Washer, Lock, 5/16"
07 110691 Nut, 5/16"-18
08 175421 Transmission, 3 Fwd. and 1 Rev.
09 123211 Bolt, 5/16"-18 x 3/4" HCS
10 165421 Cover, Transmission, F/B Scout
11 111731 Screw, 5/16"-18 x 1/2", Tri-Lobe
12 172721 Lever, Shift, F/B Scout
13 150471 Grip, 1" OD Tube, 4.25" L
14 165141 Washer, Flat, .385" ID x 1.390" OD
15 150771 Nut, Nylon Lock, 3/8"-24
16 172731 Plate, Chain Adjuster
17 150481 Pulley, Flat Idler, 1-7/8" OD
18 110751 Nut, Nylon Lock, 3/8"-16
19 165491 Screw, 1/4"-20 x 5/8", Self-Tapping
20 126861 Bolt, 3/8"-16 x 2" HCS
21 112391 Washer, Flat 3/8" USS
22 123371 Bolt, 3/8"-16 x 2-3/4" HCS
23 173371 Bushing, Traction Drive Idler
24 150611 Idler Arm, Traction Drive
25 113071 Pulley, Flat Idler, 2-1/4"
26 157121 Bolt, 3/8"-16 x 2-1/4" HCS
27 150501 Spring, e, .438" OD x .045" wire
28 112371 Washer, Flat, 10-24 USS
29 101811 Washer, Lock, 1/4"
30 173331 Guide, Belt, Trans Pulley
31 111461 Bolt, 1/4"-20 x 2-1/2" HCS
32 175381 Cable, Traction Drive
33 165391 Anchor, Wheel Drive Cable
34 173321 Pulley, V-belt, 7", F/B Scout
35 150061 Belt, A31K, 1/2" x 33"
36 175601 Pulley, Trans Drive, 2-3/4"
Ref# Part# Description
37 165151 Washer, .385" ID x .691" OD
38 165131 Bolt, 3/8"-24 x 1-1/4" GR 8
39 165431 Guide, Engine Belt, F/B Scout
40 119831 Bolt, 1/4"-20 x 3/4" HCS
41 112481 Washer, Lock, 1/4"
42 112381 Washer, Flat 1/4"
43 175521 Bolt, Eye 10-24
44 118731 Nut, Nylon Lock, 10-24
45 111241 Ring, Retaining, 5/8", Type SH
46 134431 Bolt, 5/16"-18 x 1-1/2" HCS
