42 DR
®
SCOUT
FIELD and BRUSH MOWER
Parts List - Differential and Wheel Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 180171 Differential, 700-268
02 108921 Flange, Ball Bearing, 2-hole
03 152171 Bearing, Ball, 3/4" Bore
04 123211 Bolt, 5/16"-18 x 3/4" HCS
05 110761 Nut, Nylon Lock, 5/16"-18
06 175431 Wheel, 14.5" x 7-6 2ply, F/B Scout
07 111481 Bolt, 1/4"-20 x 1-3/4" HCS
08 110731 Nut, Nylon Lock, 1/4"-20
09 180151 Chain, #40, 77 Link w/ML
