DR SCOUT User Manual

40 DR
®
SCOUT

FIELD and BRUSH MOWER
Parts List - Brush Deck Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 165341 Frame, Main, w/Engine Plate
02 173361 Plate, Deck, F/B Scout
03 165351 Deck, 22", F/B Scout
04 123211 Bolt, 5/16"-18 x 3/4" HCS
05 110751 Nut, Nylon Lock, 3/8"-16
06 165451 Strap, Anti-Rotation, Clutch
07 123361 Bolt, 5/16"-18 x 1-1/4" HCS
08 112501 Washer, Lock, Split, 5/16"
09 110761 Nut, Nylon Lock, 5/16"-18
10 175521 Bolt, Eye, 10-24
11 118731 Nut, Nylon Lock, 10-24
12 175401 Clutch, PTO, F/B Scout
13 112431 Washer, Lock, Split, 5/16"
14 165141 Washer, Flat, .385" ID x 1.390" OD
15 175441 Spindle Housing, Brush Deck
16 119851 Bolt, 3/8"-16 x 1-1/2"
17 175371 Blade, Air-Tip, 22", F/B Scout
18 101771 Washer, .64" ID x 2.5" OD
19 175451 Bolt, 5/8"-11 UNC 1-1/4" HHCS
20 111531 Bolt, 3/8-16 x 2-1/4" HCS
21 173311 Bushing, Deck Tensioner
Ref# Part# Description
22 165471 Arm, Idler, F/B Scout
23 101621 Spring, e, .750" OD x .105" wire
24 179261 Bolt, 3/8"-16 x 3-1/2", GR 5
25 178801 Pulley, Deck Drive, 4.5"
26 101191 Key, Square, 3/16" x 2"
27 114431 Belt, 4L450, 1/2" x 45"
28 123431 Bolt, Hex, 3/8"-16 x 4-1/2"
29 179051 Cam, Blade Engage
30 179061 Spring, e, .750" OD x .105" wire
31 150501 Spring, e, .438" OD x .045" wire
32 178991 Cable, Blade Engage, F/B Scout
33 165381 Access Panel, F/B Scout
34 143661 Knob, Handlebar, 5/16"-18
35 165371 Push Tube w/Skid, F/B Scout
36 134431 Bolt, 5/16"-18 x 1-1/2" HCS
37 180121 Pulley, Flat Idler, 3.25"
38 Deleted
Items Not Illustrated
39 112381 Washer, Flat, 1/4" USS
40 109481 Cap, 1", Round
41 140021 Tubing, 1/2"
