36 DR
®
SCOUT
FIELD and BRUSH MOWER
CHAPTER 7
PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY
Parts List - Handlebar Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 165361 Handlebar Assy w/Control Panel
02 120301 Screw, 3/8"-16 x 1-1/2", Tri-Lobe
03 Deleted
04 165201 Switch, Snap-In
05 157201 Key, AT2 Ignition Switch
06 139051 Cable, Throttle, 50"
07 150491 Screw, 8-32 x 1/2"
08 165171 Lever, Wheel Clutch, 1"
09 164951 Grip, Handlebar, Ergonomic, 1"
10 164971 Guard, Switch
11 175381 Cable, Traction Drive,
12 180951 Lever, Blade Engage, w/ Switch
and Harness Adapter
13 164961 Grip, Handlebar, Plain, 1"
14 178991 Cable, Blade Engage, F/B Scout
15 109161 Bolt, Eye
16 110691 Nut, 5/16"-18
17 110761 Nut, Nylon Lock, 5/16"-18
18 179231 Screw, M6 x 25mm
19 181731 Operator Presence, w/Switch and
Harness adapter
Items Not Illustrated
193591 Assembly and Operation Manual,
F/B Scout
152131 Engine Manual, B&S, All Intek
180941 Wire Harness, B&S
112141 Cable Tie, 7-1/2", black
Safety and Information Labels
162651 Label, Control Panel, F/B Scout
179111 Label, Deck, F/B Scout
173351 Label, Gear Shift, F/B Scout
179251 Label, Shift Lever, F/B Scout
124371 Label, American Flag
127811 Label, Warning, Add Oil
136491 Label, Danger
136831 Label, Caution Hot Surface
137581 Label, Check Oil
148231 Label, Safety Icons
To Next Page
