Supplement | Area Control Unit 13
Overview
4.3 Layout of an area control unit with digital display
Illustration (example)
47547
No. Designation
1 Interfaces to the Dräger Alarm Management System (Alarm System Inter-
face)
2 Volume flow measurement (VoluCount)
3 Interface to an external monitoring system (relay modules for dry contacts)
4 Transmission of door opening alarms to the Dräger Alarm Management Sys-
tem (Analog Input Module)
5 Power supply unit, 230 V AC, 24 V DC, 0.5 A for door opening alarm
6 Power supply unit, 230 V AC, 12 V DC, 1.5 A
7 Terminal blocks
1
7
3
6
2
4 5
