Function description Babylog 8000
10.10 Display PCB (Babylog 8000/Babylog 8000 SC with LC Display)
The Display PCB contains the control electronics for the LED array of the bargraph.
Fig. 24: Block diagram of the Display PCB
RAM
Modul 06
Data bus
Adress bus
Chip Select
