Reprocessing instructions | Perseus A500 9
Reprocessing
Removing the breathing hoses
● Remove the breathing hoses (C) from the ports on the breathing system. When
removing the breathing hoses, always hold them by the connection sleeve and
not by the hose itself.
Removing the filters
● Remove the filters at positions (D) or (E).
3.4.2 Device-specific components
The device-specific components must be removed from the device and, if
necessary, disassembled.
Remove the following components:
–CO
2 absorber
– Flexible breathing bag arm (option)
– Breathing system
– Flow sensors
– Inspiratory port and expiratory port
– Lower part of the breathing system and upper part of the breathing system
– APL valve
– Inspiratory valve (red) and expiratory valve (blue)
– CLIC adapter (option)
– TurboVent 2 blower module
10393
