4.2 Calibration procedure for oxygen
4.2.1 Zero calibration
Zero calibration is not required for the oxygen version of the
Polytron 5000.
4.2.2 Span calibration
z The span calibration of an oxygen sensor requires oxygen
calibration gas or ambient air. Normally a cylinder
containing 20.9
% O
2
is used to match the atmospheric
concentration.
1. Fit the calibration adapter tightly to the end of the sensor if
calibrating with a cylinder containing oxygen. Alternatively,
if you want to calibrate the span using ambient air, leave
the adapter off and skip the next two steps.
2. Attach the pressure regulator to the calibration gas cylinder
containing 20.9
% O
2
.
3. Turn the gas flow on.
4. Scroll through software menu to Span Adj.
5. Wait for the signal to stabilize.
6. Trim the stabilized value to the calibration gas
concentration (normally 20.9
%) using the Up and Down
arrows.
7. Accept the value by tapping OK with the magnetic wand.
8. Turn off the gas flow and remove the calibration adapter
from the sensor.
4.3 Error messages
5 Disposal of electrical and electron-
ic equipment
NOTICE
Allow the gas to flow for at least three minutes before
proceeding.
Error Code Condition Solution
pls con snsr no sensor is
connected
connect sensor
sensor connection
is bad
check to ensure
sensor is seated in
connector
snr err unsupported
sensor is
connected or
sensor EEPROM
data is corrupted
install supported
sensor
flt hardware fault replace electronics
AFE err wrong software
version installed in
analog front end
(AFE)
install most recent
AFE software
defective AFE replace electronics
AFE out AFE
microcontroller is
out of its socket or
not installed
check
microcontroller
defective AFE replace electronics
i
i
EC-wide regulations for the disposal of electrical and
electronic equipment, which have been defined in the
EU Directive 2002/96/EC and in national laws, have
been effective since August 2005 and apply to this
device. Common household appliances can be
disposed of using special collecting and recycling
facilities. However, as this device has not been
registered for household usage, it must not be
disposed of through these means. The device can be
returned to your national Dräger Sales Organization
for disposal. Please do not hesitate to contact Dräger
if you have any further questions on this issue.
