Dräger Polytron 5000 User Manual

Order list
Dräger Polytron 5000 13
8 Order list
8.1 Sensors
8.2 Accessories
8.3 Spare parts
Description
Part Number
Polytron 5000, DS d A 4544120
Polytron 5000, DS d S 4544122
Polytron 5000, DS d A General Purpose 4544165
Description
Part Number
DrägerSensor CO 6809605
DrägerSensor H
2
S 6810435
DrägerSensor H
2
S LC 6809610
DrägerSensor H
2
S HC 6809710
DrägerSensor O
2
LS 6809630
DrägerSensor H
2
6809685
DrägerSensor NH
3
LC 6809680
1
1) Only to be used with Polytron 5000 General Purpose part number
4544165.
DrägerSensor NH
3
HC 6809645
1
DrägerSensor Cl
2
6809665
1
DrägerSensor SO
2
6809660
1
DrägerSensor NO 6809625
2
2) Notice: Gases which react with moisture will not repeatedly pass
through the wire mesh, if the transmitter is installed in a non-
climate controlled environment. If it can be ensured, that
condensation on the wire mesh will not occur; all sensors can be
used in the explosion proof versions 4544120, 4544122.
Otherwise, these sensors should only be used with Polytron 5000
General Purpose 4544165.
DrägerSensor NO
2
6809655
1
DrägerSensor H
2
O
2
LC 6809705
1
DrägerSensor EO 6810740
2
Description
Part Number
Pipe Mount Kit 4544198
Magnet with Key Chain 4544101
Splash Guard 6812510
Calibration Adapter PE 4509314
Calibration Adapter PE, Europe 6806978
Calibration Adapter Viton 6810536
Calibration Kit (includes carrying case,
calibration adapter 4509314, 500 cc/min
cylinder regulator 4557020 and 100
% N
2
103 L @ 1000 PSI nitrogen / zero gas
cylinder)
4594620
Calibration Gases on request
Description
Part Number
Bezel Polytron 5000 4544184
PCB Main Polytron 5000 4544185
PCB Filter Polytron 5000 4544252
Sensor Housing Complete 4544189
Sensor Cap 4544190
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Dräger Polytron 5000 Specifications

General

Type	Gas Detector
Housing Material	Aluminum or Stainless Steel
Detection Principle	Electrochemical sensor
Gases Detected	Oxygen, Toxic and Combustible gases
Display	Backlit LCD
Output Signal	4 to 20 mA, HART
Operating Temperature	-40 °C to +65 °C (depending on the sensor)
Ingress Protection	IP66
Approvals	ATEX, IECEx
Humidity	0 to 95% RH, non-condensing
