Dräger Polytron 5100 - Explosion Proof Instrument with Increased Safety Wiring Compartment (Docking Station)

Description
Dräger Polytron 5100 7
2.1.2 Explosion proof instrument with increased safety
wiring compartment (Docking Station)
4544911
c
1
2
3
4
6
7
8
5
9
4544911
d
1 Enclosure lid
2 Bezel with main electronics
3 Relay board (optional)
4 Enclosure bottom
5 Sensor
6 Feed-through cable
7 Field wire terminals in Docking Station
8 Docking Station
9 Assembled instrument
