Section 7
Troubleshooting
Troubleshooting
WARNING:
Only facility-authorized personnel must troubleshoot the Resuscitaire Radiant Warmer
products. Troubleshooting by unauthorized personnel could result in personal injury or
equipment damage.
For troubleshooting of the equipment, refer to the table on page 7-1. If you cannot localize the fault,
remove the unit from use, and refer it to factory-trained or other qualified service personnel.
Troubleshooting
Symptom Possible Cause Corrective Action
There is no power, and the
Power Fail alarm does not acti-
vate.
The circuit breaker on the con-
troller is not set to ON.
Set the circuit breaker to ON.
Allow the warmer to run with the
power switched ON for > 3 min
to charge the supercap.
The Power Fail alarm activates. The circuit breaker on the con-
troller is tripped.
Reset the circuit breaker.
The power cable is unplugged. Plug the power cable into the
POWER connector on power
input.
The power cable is damaged. Replace the power cable.
The System Fail alarm activates.
An error code appears.
There is an internal malfunction. Refer the unit to service.
The System Fail alarm activates.
No error code appears.
There was a prolonged brown-
out.
This alarm is not resettable.
Refer the unit to service.
The Probe Fail alarm activates. The skin probe is disconnected. Connect the skin probe to the
infant skin. If the skin probe is
plugged into the probe recepta-
cle, the tip of the probe must be
in contact with the infant skin. If
not, remove the skin probe.
The skin probe is damaged. Ensure that the skin probe is in
good contact with the skin. If the
problem still exists, replace the
skin probe, then refer the unit to
service.
Blender alarm activates. Oxygen and/or air are discon-
nected.
Connect oxygen and/or air.
To Next Page
