PROPRIETARY AND CONFIDENTIAL DRAFT 5 Feb 04
2 - 20
Height (RW82) 190.5 cm (75")
Height w/VHA including Vari-tilt (RW82) maximum of 201 cm (maximum of 79")
Bassinet Width (side-to-side) (RW82) 57.1 cm (22.5")
Bassinet Depth (front-to-back) (RW82) 71.1 cm (28")
Width (side-to-side) (WBR82) 71.1 cm (28")
Width (side-to-side) (RW82) ≤ 68.6 cm (27")
Depth (front-to-back) (WBR82) (with cart) 121.9 cm (48")
Depth (front-to-back) (RW82) ≤ 116.8 cm (46")
Weight w/Warmer and Cart (WBR82) 145.1 kg (320 lbs.)
Weight (RW82) 117.9 kg - 131.5 kg (260 - 290 lbs.) depending on
options installed
Weight w/VHA (RW82) 122.5 kg - 136 kg (270 lbs. - 300 lbs.) depending
on options installed
Weight w/Bracket (WMRW82) 18.1 kg (40 lbs.)
Warmer Head Rotation ±90 °
Accessory Poles (2 each) (RW82 only) 38-mm diameter x 600 mm
Accessory Pole Weight Limit 6 kg (13.2 lb) each or combined weight of 12 kg
(26.5 lb)
Instrument Tray Dimensions 33.0 cm (13") x 22.8 cm x (9.0")
Instrument Tray Weight Limit 2.2 kg (5 lb)
CYLINDERS
N
O
TE:
To determine proper cylinder length, fully lower the
VHA and measure from the center line of the gas
inlet to the floor.
Cylinder Diameter 10 cm (4") minimum/12 cm (5") maximum
Cylinder Length 43 cm (16.9") to 80 cm (31.5")
Cylinder Fittings DIN, AFNOR, UNI, Pin Index (NIST, DISS),
AGA
Cylinder Size E size
PRESSURE REGULATORS
Standard Setting
Input Pressure 0 to 3000 psi
Factory Set Output Pressure 65 psi ± 3 psi @ 1200-psi input pressure, no flow
Optional Low-Pressure Settings
Input Pressure 0 to 3000 psi
Factory Set Output Pressure 45 psi ± 3 psi @ 1500-psi input pressure, no flow
50 psi + 5 psi/_ 0 psi @ 1500-psi input pressure,
no flow
Feature Dimension
