Dragino LLDS40 User Manual

2.! Configure LLDS40 to connect to LoRaWAN
network
2.1! How it works
The LLDS40 is configured as LoRaWAN OTAA Class A mode by default. It has OTAA keys to join
LoRaWAN network. To connect a local LoRaWAN network, you need to input the OTAA keys in the
LoRaWAN IoT server and power on the LLDS40. It will automatically join the network via OTAA and start
to send the sensor value. The default uplink interval is 20 minutes.
In case you can't set the OTAA keys in the LoRaWAN OTAA server, and you have to use the keys from the
server, you can
use AT Commands!
to set the keys in the LLDS40.
2.2! Quick guide to connect to LoRaWAN server (OTAA)
Following is an example for how to join the
TTN v3 LoRaWAN Network
(
https://console.cloud.thethings.network/
)
. Below is the network structure; we use the
LG308
(
http://www.dragino.com/products/lora/item/140-lg308.html
)
!as a LoRaWAN gateway in this example.!
