Draytek Vigor2133 User Manual

Vigor2133 Series User’s Guide
9
9
I
I
I
I
-
-
2
2
-
-
4
4
L
L
A
A
N
N
P
P
o
o
r
r
t
t
M
M
i
i
r
r
r
r
o
o
r
r
The LAN Port Mirror function allows network traffic of select LAN ports to be forwarded to
another LAN port for analysis. This is useful for enforcing policies, detecting unauthorized
access, monitoring network performance, etc.
Select LAN>>LAN Port Mirror from the menu bar of the Web UI to bring up the LAN Port
Mirror configuration page.
Available settings are explained as follows:
Item Description
Port Mirror Enables or disables LAN Port Mirroring.
Mirror Port One and only one port is selected as the mirror port, to
which traffic is to be forwarded.
Mirrored Tx Port Port(s) whose outbound traffic will be forwarded to the
mirror port.
Mirrored Rx Port Port(s) whose inbound traffic will be forwarded to the mirror
port.
After finishing all the settings here, please click OK to save the configuration.
