Vigor2133 Series User’s Guide
401
Select Device and Selected Device areas.
Selected Device Display the access points that will be applied by such function
after clicking OK.
After finishing all the settings here, please click OK to perform the action.
V
V
I
I
-
-
4
4
-
-
4
4
T
T
r
r
a
a
f
f
f
f
i
i
c
c
G
G
r
r
a
a
p
p
h
h
Click Traffic Graph to open the web page. Choose one of the managed Access Points, LAN-A
or LAN-B, daily or weekly for viewing data transmission chart. Click Refresh to renew the
graph at any time.
The horizontal axis represents time; the vertical axis represents the transmission rate (in
kbps).
Info
Enabling/Disabling such function will also enable/disable the External
Devices function.
