Vigor2133 Series User’s Guide
115
Available settings are explained as follows:
Item Description
Enable Check to enable this entry.
Service Choose the predefined service to apply for such trigger
profile.
Comment Type the text to memorize the application of this rule.
Source IP Use the drop down list to specify an IP object. Or click IP
Object link to create a new one for applying.
Triggering Protocol Select the protocol (TCP, UDP or TCP/UDP) for such
triggering profile.
Triggering Port Type the port or port range for such triggering profile.
Incoming Protocol When the triggering packets received, it is expected the
incoming packets will use the selected protocol. Select the
protocol (TCP, UDP or TCP/UDP) for the incoming data of
such triggering profile.
Incoming Port Type the port or port range for the incoming packets.
After finishing all the settings here, please click OK to save the configuration.
