High-Encapsulating Security Payload (ESP) means payload
(data) will be encrypted and authenticated. You may select
encryption algorithm from Data Encryption Standard (DES),
Triple DES (3DES), and AES.
Local ID (Optional)- Specify a local ID to be used for Dial-in
setting in the LAN-to-LAN Profile setup. This item is optional
and can be used only in IKE aggressive mode.
After finishing all the settings here, please click OK to save the configuration.
I
I
V
V
-
-
1
1
-
-
8
8
L
L
A
A
N
N
t
t
o
o
L
L
A
A
N
N
Here you can manage LAN-to-LAN connections by maintaining a table of connection profiles.
You may set parameters including specified connection direction (dial-in or dial-out),
connection peer ID, connection type (VPN connection - including PPTP, IPsec Tunnel, and
L2TP by itself or over IPsec) and corresponding security methods, etc.
Available settings are explained as follows:
Item Description
Set to Factory Default Click to clear all indexes.
Name Indicate the name of the LAN-to-LAN profile. The symbol ???
represents that the profile is empty.
Active V – means the profile has been enabled.
X – means the profile has not been enabled.
Status Online – means such LAN to LAN profile is in use.
Offline – means such LAN to LAN profile isn’t in use even if
the profile has been enabled.
To edit each profile:
