Address Type Determine the address type for the IP address.
Select Single Address if this object contains one IP address
only.
Select Range Address if this object contains several IPs
within a range.
Select Subnet Address if this object contains one subnet for
IP address.
Select Any Address if this object contains any IP address.
Select Mac Address if this object contains Mac address.
MAC Address Type the MAC address of the network card which will be
controlled.
Start IP Address Type the start IP address for Single Address type.
End IP Address Type the end IP address if the Range Address type is
selected.
Subnet Mask Type the subnet mask if the Subnet Address type is selected.
Invert Selection If it is checked, all the IP addresses except the ones listed
above will be applied later while it is chosen.
4. After finishing all the settings here, please click OK to save the configuration. Below is
an example of IP objects settings.
