Vigor2133 Series User’s Guide
505
n=2: Dynamic IP
n=3: Static IP
n=4: PPTP with Dynamic IP,
n=5: PPTP with Static IP,
n=6: L2TP with Dynamic IP
n=7: L2TP with Static IP
n=A: 3G/4G USB Modem(PPP mode)
n=B: 3G/4G USB Modem(DHCP mode
-S <isp name> It means to set ISP Name (max. 23 characters).
-P <on/off> It means to enable PPPoE Service.
-u <username> It means to set username (max. 49 characters) for Internet
accessing.
-p <password> It means to set password (max. 49 characters) for Internet
accessing.
-a n It means to set PPP Authentication Type and n means different
types (represented by 0-1).
n=0: PAP/CHAP (this is default setting)
n=1: PAP Only
-t n It means to set connection duration and n means different
conditions.
n=-1: Always-on
n=1 ~ 999: Idle time for offline (default 180 seconds)
-i <ip address> It means that PPPoE server will assign an IP address specified here
for CPE (PPPoE client).
If you type 0.0.0.0 as the <ip address>, ISP will assign suitable IP
address for you. However, if you type an IP address here, the router
will use that one as a fixed IP.
-w <ip address> It means to assign WAN IP address for such connection. Please type
an IP address here for WAN port.
-n <netmask> It means to assign netmask for WAN connection. You have to type
255.255.255.xxx (x is changeable) as the netmask for WAN port.
-g <gateway> It means to assign gateway IP for such WAN connection.
-s <server ip> Set PPTP/L2TP Server IP.
<server ip>= ppp.qqq.rrr.sss: PPTP/L2TP server IP
-A <idx> Set to Always On mode, and <idx> as backup WAN#.
-B <mode> Set to Backup mode;
<mode> 0: When any WAN disconnect; 1: When all WAN disconnect.
-V It means to view Internet Access profile.
-C <sim pin code> Set SIM PIN code (max. 15 characters) for USB PPP mode.
-O <init string> Set Modem Initial String (max. 47 characters) for USB PPP mode.
-T <init string2> Set Modem Initial String2 (max. 47 characters) for USB PPP mode.
-D <dial string> Set Modem Dial String (max. 31 characters) for USB PPP mode.
-v <service name> Set Service Name (max. 23 characters) for USB PPP mode.
-m <ppp username> Set PPP Username (max. 63 characters) for USB PPP mode.
-o <ppp password> Set PPP Password (max. 62 characters) for USB PPP mode.
-e n Set PPP Authentication Type for USB PPP mode.
n= 0: PAP/CHAP (default),
1: PAP Only
-q n Set the first schedule for USB PPP mode.
