Path MTU to – Type the IP address as the specific
transmit path.
MTU size start from - Determine the starting point
value of the packet.
MTU reduce size by – It determines the decreasing size
of MTU value. For example, the number specified in
this field is “8”. The maximum MTU size is “1500”.
After clicking the “detect” button, the system will
calculate and get the suitable MTU value such as 1500,
1492, 1484 and etc., automatically.
Detect – Click it to detect a suitable MTU value
Accept – After clicking it, the detected value will be
displayed in the field of MTU.
TTL Change the TTL value – Enable or disable the TTL (Time to
Live) for a packet transmitted through Vigor router.
Enable - TTL value will be reduced (-1) when it passess
through Vigor router. It will cause the client, accessing
Internet through Vigor router, be blocked by certain ISP
when TTL value becomes “0”.
Disable – TTL value will not be reduced. Then, when a packet
passes through Vigor router, it will not be cancelled. That is,
the client who sends out the packet will not be blocked by
ISP.
PPP/MP Setup PPP Authentication – Select PAP only or PAP or CHAP for
PPP.
Idle Timeout – Set the timeout for breaking down the
Internet after passing through the time without any action.
IP Address Assignment
Method (IPCP)
Usually ISP dynamically assigns IP address to you each time
you connect to it and request. In some case, your ISP
provides service to always assign you the same IP address
whenever you request. In this case, you can fill in this IP
address in the Fixed IP field. Please contact your ISP before
you want to use this function.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use
WAN IP Alias. You can set up to 32 public IP addresses other
than the current one you are using. Type the additional WAN
