Draytek Vigor2830 Series User Manual

Vigor2830 Series User’s Guide
137
Available settings are explained as follows:
Item Description
Enable
Check to enable the DMZ Host function.
Private IP
Enter the private IP address of the DMZ host, or click
Choose PC to select one.
Choose PC
Click this button and then a window will automatically pop
up, as depicted below. The window consists of a list of
private IP addresses of all hosts in your LAN network.
Select one private IP address in the list to be the DMZ host.
When you have selected one private IP from the above
dialog, the IP address will be shown on the following
screen. Click OK to save the setting.
After finishing all the settings here, please click OK to save the configuration.
