The router supports a new feature that single PVC can offer more than one service. The
following illustration shows how to bind the functions of NAT and Bridge processed with one
PVC.
From the above figure, Setop Box and DHCP server can reach for each other through
WAN5 with Bridge mode; LAN PC in P1 beneath Vigor router can reach to PPPoE
Server through WAN1 with NAT. Both NAT and Bridge are built through the same
Channel 1.
Follow the steps listed below to configure the settings:
1. Log into the web user interface of Vigor router.
2. Open WAN>>Internet Access. Only PPPoE and MPoA 1483 Bridge can support PVC to
PVC Binding feature, you have to choose PPPoE/PPoA as the Access Mode for WAN1.
