Vigor2830 Series User’s Guide
171
To set a new profile, please do the steps listed below:
1. Click the number (e.g., #1) under Index column for configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item Description
Name
Type a name for this profile. Maximum 15 characters are
allowed.
Interface
Choose a proper interface.
For example, the Direction setting in Edit Filter Rule will
ask you specify IP or IP range for WAN or LAN/RT/VPN
or any IP address. If you choose LAN/RT/VPN as the
Interface here, and choose LAN/RT/VPN as the direction
setting in Edit Filter Rule, then all the IP addresses
specified with LAN/RT/VPN interface will be opened for
you to choose in Edit Filter Rule page.
