Draytek Vigor2830 Series User Manual

Vigor2830 Series User’s Guide
233
Regular Mode– Mostly it is the same with anonymous mode.
The different is that, the server will firstly check if you have
the search authority.
For the regular mode, you’ll need to type in the Regular DN
and Regular Password.
Server Address
Enter the IP address of LDAP server.
Destination Port
Type a port number as the destination port for LDAP server.
Use SSL
Check the box to use the port number specified for SSL.
Regular DN
Type this setting if Regular Mode is selected as Bind Type.
Regular Password
Specify a password if Regular Mode is selected as Bind
Type.
After finished the above settings, click OK button to save the settings.
P
P
r
r
o
o
f
f
i
i
l
l
e
e
s
s
You can configure eight AD/LDAP profiles. These profiles would be used with User
Management for different purposes in management.
