Vigor2830 Series User’s Guide
285
Codec
Display the codec type for the account.
Ring Port
Specify which port will ring when receiving a phone call.
Status
Show the status for the corresponding SIP account. R
means such account is registered on SIP server
successfully. – means the account is failed to register on
SIP server.
STUN Server
Type in the IP address or domain of the STUN server.
External IP
Type in the gateway IP address.
SIP PING interval
The default value is 150 (sec). It is useful for a Nortel
server NAT Traversal Support.
Click any index link to access into the following page for configuring SIP account.
Available settings are explained as follows:
Item Description
Profile Name
Assign a name for this profile for identifying. You can type
similar name with the domain. For example, if the domain
name is draytel.org, then you might set draytel-1 in this
field.
Register via
If you want to make VoIP call without register personal
To Next Page
