Draytek Vigor2830 Series User Manual

Vigor2830 Series User’s Guide
290
D
D
e
e
t
t
a
a
i
i
l
l
e
e
d
d
S
S
e
e
t
t
t
t
i
i
n
n
g
g
s
s
f
f
o
o
r
r
P
P
h
h
o
o
n
n
e
e
P
P
o
o
r
r
t
t
Click the number link for Phone port, you can access into the following page for configuring
Phone settings.
Available settings are explained as follows:
Item Description
Hotline
Check the box to enable it. Type in the SIP URL in the field
for dialing automatically when you pick up the phone set.
Session Timer
Check the box to enable the function. In the limited time
that you set in this field, if there is no response, the
connecting call will be closed automatically.
T.38 Fax Function
Check the box to enable T.38 fax function.
Error Correction Mode – choose a mode for error
correction.
DND (Do Not Disturb)
mode
Set a period of peace time without disturbing by VoIP
phone call. During the period, the one who dial in will listen
busy tone, yet the local user will not listen any ring tone.
Index (1-15) in Schedule - Enter the index of schedule
profiles to control when the phone will ring and when will
not according to the preconfigured schedules. Refer to
section Application >>Schedule for detailed configuration.
Index (1-60) in Phone Book - Enter the index of phone
book profiles. Refer to section DialPlan – Phone Book for
detailed configuration.
CLIR (hide caller ID)
Check this box to hide the caller ID on the display panel of
the phone set.
