Vigor2830 Series User’s Guide
294
Port
It shows current connection status for Phone(s) ports.
Status
It shows the VoIP connection status.
IDLE - Indicates that the VoIP function is idle.
HANG_UP - Indicates that the connection is not
established (busy tone).
CONNECTING - Indicates that the user is calling out.
WAIT_ANS - Indicates that a connection is launched and
waiting for remote user’s answer.
ALERTING - Indicates that a call is coming.
ACTIVE-Indicates that the VoIP connection is launched.
Codec
Indicates the voice codec employed by present channel.
PeerID
The present in-call or out-call peer ID (the format may be
IP or Domain).
Elapse
The format is represented as hours:minutes:seconds.
Tx Pkts
Total number of transmitted voice packets during this
connection session.
Rx Pkts
Total number of received voice packets during this
connection session.
Rx Losts
Total number of lost packets during this connection session.
Rx Jitter
The jitter of received voice packets.
In Calls
Accumulation for the times of in call.
Out Calls
Accumulation for the times of out call.
Miss Calls
Accumulation for the times of missing call.
Speaker Gain
The volume of present call.
Log
Display logs of VoIP calls.
