Dremel 3D40 FLEX - Page 16

16
Initial Setup
4. The flexible build plate can be installed on
top of the build plate holder by sliding it
backwards at an angle so that the corners
of the flexible build plate slide under the
notches at the back of the build plate
holder. Release the flexible build plate so
it sticks on top of the magnet, and close
the latches at the front to hold it in place.
TIP: It is much easier to remove and
install the flexible build plate if the build
plate holder is already installed in the
printer. In general, once the build plate
holder is installed in the printer you do not
need to remove it, you only need to
remove the flexible build plate.
5. The build plate holder can be removed by
pinching the clip located at the front of the
build platform and lifting the build plate
holder off the base, figure 7.
6. Install the build plate holder using the build
platform clips.
P
R
E
S
S
L
I
F
T
FIG. 7
Clip
Clip
Clip
