15
PREPARING BUILD PLATE
Do not drop the build
plate. Tempered glass
plate may break and result in personal injury.
Do not remove
tempered glass plate
from plastic holder. Contacting with
tempered glass plate edge may result in
personal injury.
Before every build make
sure that the flexible
build plate is covered with Dremel specified
build tape. Use of improper build tape may
result in equipment damage and poor object
build quality.
1. Your build plate consists of two parts: the
flexible build plate, and the build plate
holder. The build plate holder has a
magnetic surface to attach the flexible
build plate to, and it has two notches in
the back and movable latches in the front
to hold down the corners of the flexible
build plate.
2. The flexible build plate can be removed
from the build plate holder by rotating the
movable latches towards you (A), lifting
the flexible build plate up by the blue
handles (B), and pulling it out towards you
(C), figure 5.
3. The flexible build plate comes with build
tape installed. To remove it, lift it up from
the tab at the front corner and slowly peel
off. To install a new build tape, remove
adhesive liner from build tape and place
build tape over flexible build plate. For
best results, apply build tape at center of
flexible build plate and smooth outward to
remove any air bubbles, figure 6.
Build
Tape
Flexible
Build
FIG. 6
FIG. 5
Initial Setup
Flexible Build
Plate
Build Plate
Holder
Latches
Handle
Handle
Notch
Notch
