6
XT SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Table 6-1:
XT Series humidifier dimensions by model number
Dimension Description
Model XTP
002, 003, 006 010, 017 025, 033, 042, 048 050, 067, 083, 096
inches mm inches mm inches mm inches mm
A Cabinet width 14.6 370 17.7 450 19.9 504 39.6 1005
B Cabinet height 20.6 523 24.1 612 25.6 650 25.6 650
C Cabinet depth 8.7 221 11.8 300 13.4 340 13.4 340
D
Cabinet back edge to steam/drain outlet
centers
4.5 114 6.0 152 6.7 170 6.7 170
E Cabinet left edge to steam/drain outlet centers 4.4 112 6.0 152 7.0 178 7.0 178
F
Cabinet back edge to supply water connection
center
6.7 170 9.5 241 11.1 282 11.1 282
G
Cabinet left edge to supply water connection
center
1.0 25 1.0 25 1.1 28 1.1 28
Table 6-2:
XT Series humidifier weights by model number
Model XTP
002, 003 006 010, 017 025, 033, 042, 048 050, 067, 083, 096
lbs kg lbs kg lbs kg lbs kg lbs kg
Shipping weight 37 17 37 17 50 23 64 29 139 63
Maximum operating weight 38 17 46 21 79 36 115 52 219 99
Dimensions and weights
SPECIFICATIONS
