XT SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
WARNING
Standing water in XT steam blower
Make sure the XT steam blower is installed plumb. If it is not installed plumb, standing
water can accumulate, which can:
• cause bacteria and mold growth, which can cause illness;
• affect XT steam blower performance;
• cause 212 °F (100 °C) water to discharge from the XT steam blower, which can
cause severe personal injury.
REMOTE MOUNTING XT STEAM BLOWER
The XT steam blower is constructed with a pitch toward the drain; however, it
must be installed level and plumb for proper drainage. See the Warning.
INSTALLING BASE PLATE
The steam blower has a base plate for remote-mounted steam blower
applications. The base plate isolates the hot steam box from contact. After the
electrical connections are made, assemble the base plate onto the bottom of
the steam blower with the screws provided.
INSTALLATION
XT steam blowersDispersion:
Follow the instructions below for your wall type:
Mount the XT steam blower using the lag bolts provided. Follow the instructions
below for mounting on a wood stud wall.
1. Mount spanner board on wall, spanning at least two studs, at top of XT
steam blower cabinet (for the lag bolts).
2. Predrill pilot holes in spanner board, and secure XT stream blower to
spanner board with lag bolts.
Note: Use the appropriate mounting methods and mounting hardware for
other wall types.
See Table 40-1 to determine clearance requirements for your application.
Make sure walls, ceilings, and other obstructions are not within the non-wetting
dimension, or condensation and dripping could occur (read Page 40).
Provide at least 3" (76 mm) of clearance on each side of the XT steam blower
for air intake.
