29
CORRECT
When installing bed rail, only place one (1)
rail on bed per side.
INCORRECT
DO NOT place 2 bed rails on the same
side of the bed as shown above.
WARNING - INCORRECT MOUNTING MAY CAUSE INJURY OR DEATH
Half Bed Rails:
To install half rails, locate the label located on the head section of the frame (Fig D). The half rail clamp
should be installed over this label. Align xed clamp jaw (Fig E) in front of bed frame rail as shown below.
Align movable clamp jaw on top of bed frame rail, and turn knob clockwise until clamp is tight, securing
safety rail to bed frame rail (Fig F).
Half Bed Rail Operation: Pull out Pull Pin on each bracket to raise or lower rail. Ensure Pull Pin is properly engaged
to lock rail in position.
NOTE: Bed rails should be removed when bed is disassembled to help prevent damage.
D E F
