Inverter dimensions. Frame size 6.
Table C-8
Model
Number XTD-
Fram
e size
H1
(inches)
H2
(inches)
W1
(inches)
W2
(inches)
D1 (inches)
Hole diameter
(inches)
Weight
(lbs.)
4210-000 6 53.149 16.54 20.86 7.87 14.251 0.354 264.55
