Drivecon XT Series - Cable and Fuse sizes

Owner's Manual
Drivecon Toll Free Ph: 1-800-374-8266
Drivecon reserves the right to alter or amend the above information without notice
Cable and Fuse sizes
Inverter type
XTdor XTe-
Frame
size
Maximum full
load Amps
(continuous)
Fuse Amps
(footnote)
90°C AWG
4004 1 4 5 (1) 14
4005 1 5.4 7 (1) 14
4009 1 9 12 (1) 12
4012 1 12 15 (1) 12
4016 2 16 20 (1) 12
4022 2 22 30 (1) 10
4031 3 31 40 (2) 10
4038 3 38 50 (2) 8
4045 3 45 60 (2) 8
4061 4 61 80 (2) 6
4072 4 72 90 (2) 6
4087 4 87 110 (2) 4
4105 5 105 125 (2) 2
4140 5 140 175 (2) 1/0
4168 5 168 200 (2) 1/0
4210 6 210 250 (2) 2/0
˜.(1) 600VAC time delay class CC fuses
˜.(2) 600VAC time delay class J fuses
D-2
