XT Drive Traverse spare parts list
POS DESCRIPTION NAME REMARKS
002 003 004 005 007 011 015 018 022 030 037 045 055 075 090 110 132
A1 Inverter D2VxxxNF1e0# 11111111111111111
(includes PSU and CSU)
Power supply unit PSUxxxNF1e# 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Fan D2VSP-EPP01060 24VDC 1 1 1
Fan D2VSP-EPP01061 24VDC 1 1 1
Fan D2VSP-EPP01062 24VDC 1 1 1
Fan D2VSP-EPP01063 24VDC 1 1 1
Fan D2VSP-ECP01038 230VAC 1 1 1
Fan D2VSP-EPP01080 230VAC 1 1
Control unit CSU0# 11111111111111111
(includes boards A, B, D1)
Display keypad D2VSP-ENXPAN_A 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Basic I/O-board D2V-I/O_BOARD Slot A 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Relay / Thermistor Board D2V-NXOPTA3 Slot B 11111111111111111
SSU D2V-SSU Slot C1 11111111111111111
I/O Extension board D2V-NXOPTB9 Slot D1 11111111111111111
Profibus Board D2V-NXOPTC5 Slot E1 11111111111111111
Relay Extension Board D2V-NXOPTB5 Slot E2 11111111111111111
F7 Protective switch D2PS-GV2ME08 1 1 1 1 1 1 1 1
at F7 Auxiliary contact D2PS-GV2AN20 1 1 1 1 1 1 1 1
F71 Protective switch D2PS-GV2ME08 11111
at F71 Auxiliary contact D2PS-GV2AN20 11111
K7 Contactor D2K-LC1D09D7 42VAC 111111111111
K7 Contactor D2K-LC1D09E7 48VAC 111111111111
K7 Contactor D2K-LC1D09F7 115VAC 111111111111
K7 Contactor D2K-LC1D09P7 230VAC 111111111111
at K7 RC-filter D2K-LAD4RCE 42/48VAC 111111111111
at K7 RC-filter D2K-LAD4RCU 115/230VAC 111111111111
K71 Contactor D2K-LC1D09D7 42VAC 1 1 1 1 1
K71 Contactor D2K-LC1D09E7 48VAC 1 1 1 1 1
K71 Contactor D2K-LC1D09F7 115VAC 1 1 1 1 1
K71 Contactor D2K-LC1D09P7 230VAC 1 1 1 1 1
at K71 RC-filter D2K-LAD4RCE 42/48VAC 1 1 1 1 1
at K71 RC-filter D2K-LAD4RCU 115/230VAC 1 1 1 1 1
at K71 Auxiliary contact D2K-LAD8N20 11111
at K71 Auxiliary contact D2K-LADN04 11111
CM1 Y-capacitor D2F-KC-307-00 Supply network N 11111111111111111
Z1 Ferrite D2F-RU2100-30-7 Supply network N 1 1 1 1 1 1
Z2 Ferrite D2F-RH175285107 Supply network N 1 1 1 1 1 1
Z3 Ferrite D2F-RH175285107 Supply network N 1 1 1 1 1 1
Z1 Ferrite D2F-RU2101 Supply network N 1 1 1
Z2 Ferrite D2F-74270096 Supply network N 1 1 1
Z3 Ferrite D2F-7427015-2 Supply network N 1 1 1
Z1 Ferrite D2F-RU2102 Supply network N 1 1 1
Z2 Ferrite D2F-7427015 Supply network N 1 1 1
Z3 Ferrite D2F-742701111-7 Supply network N 1 1 1
Z2 Ferrite D2F-7427015-3 Supply network N 1 1 1 1 1
Z3 Ferrite D2F-7427015-4 Supply network N 1 1 1
Z3 Ferrite D2F-74270097-3 Supply network N 1 1
Z4 Ferrite D2F-7427015-4 Supply network N 1 1
Z4 Ferrite D2F-74270097-3 Supply network N 1
R1 Resistor D2REP90 Braking type B 1 1 1 1 2 2
R1 Resistor D2REL42 Braking type B 1
xxx defines inverter power ratin
g class ( from 002 to 132 )
e defines supply network ( 0 = unlimited, N = limited )
# defines special options ( 0 = none, 1 = varnished boards )
INTERNAL BRAKING RESISTOR
COMPONENTS FOR LIMITED SUPPLY NETWORK (GROUNDED)
# defines special options ( 0 = none, 1 = varnished boards )
SECOND BRAKE CONTACTOR
BRAKE CONTACTOR
BRAKE SUPPLY CIRCUIT BREAKER
INVERTER
xxx defines inverter power rating class ( from 002 to 132 )
e defines supply network ( 0 = unlimited, N = limited )
# defines special options ( 0 = none, 1 = varnished boards )
