Fault Counter
V4.5.1
Fault Counter Fault counter value.
Counter value is shown in format
Fault counter value. Fault number.
E.g. 12.01 means that there has been 12
pieces overcurrent faults.
When counter value is blinking, then you can
monitor fault counter values by pressing up
and down arrows.
xx.01
xx.02
xx.03
xx.07
xx.09
xx.10
xx.11
xx.12
xx.13
xx.14
xx.25
xx.41
xx.53
xx.56
xx.57
xx.61
xx.62
xx.63
xx.99
Overcurrent fault counter
Overvoltage fault counter
Earth fault counter
Saturation trip fault counter
Undervoltage fault counter
Input line supervision fault counter
Output phase supervision fault counter
Braking chopper supervision fault counter
Inverter undertemperature fault counter
Inverter overtemperature fault counter
Microprocessor watchdog-fault counter
IGBT temperature fault counter
Profibus communication error fault counter
Generator side current limit fault counter
Thermistor fault counter
Overspeed fault counter
Speed difference fault counter
Stall supervision fault counter
Sum counter of following faults:
F4, F5, F8, F22, F23, F24, F26, F31, F32, F33, F34, F35, F36, F37,
F38, F39, F40, F44, F45, F48, F50, F54, F55, F60, F64, F65, F71, F72,
F73, F74
V4.5.2
Total Faults Total number of all faults.
