Option Boards Relay board
this card plugs into slot E
No.
Name
Description, signal level
No.
Name
Description, signal level
22 ROE1 NO contact of ROE1 26 ROE2 C contact of ROE2
23 ROE1 C contact of ROE1 28 ROE3 NO contact of ROE3
25 ROE2 NO contact of ROE2 29 ROE3 C contact of ROE3
Profibus board
this card plugs into slot E
