18 GSM/GPRS Alarm Communicators
Status: Page used to check the status of the Communicator.
PTM: PTM function setup page.
The following pages only apply to the GS3125 Communicator series.
I/O: Communicator output/input parameter programming page.
Voice Dialer: Page used to set all parameters relating to the voice dialer.
SMS Dialer: Page is used to program all SMS dialer options.
Voice Message: Page used to manage voice messages.
To start the configuration of a new Customer, click on File->New.
To display the list of customers stored in the archive, select the menu command File->Open. This section will allow you to delete or retrieve
configuration data, as follows:
1. Using the right button on the mouse, click on the Customer’s name.
2. Click Load upload the respective data from the Hard-Disk, or Delete selected customer to delete the data
configuration.
You can load the configuration data by double clicking the respective name field. You can list Customers in alphabetical or code order
by clicking the heading of the column concerned. The configuration data are grouped in the following pages. The (Status) page is
for “Supervisory and Control” purposes. All the pages are described in detail in this section.
Phonebook
The Telephone Page phonebook holds 100 telephone numbers.
The Pay As You Go Balance is sent to the Telephone Number #1.
Description: Enter an alphanumeric string of up to 16 characters.
Telephone number: Enter a telephone number of up to 16 digits, preceded by the correct international prefix in the format "+xxx"
(only digits and “+” signs are accepted).
Activates Output: Select the telephone numbers which can activate the outputs T1 (OC1), T2 (OC2) and T3 (OC3) when the
Communicator receives a call from them. This function does not depend on the White List or Black List options (Options page->Dial
options). The Calling Line Identifier service must be enabled before the output can be activated.
In the GS3105 series, it is possible to only activate the T3 output (OC3).
To activate the output in the GS3125 series, programme the T1 (OC1), T2 (OC2) and T3 (OC3) terminals as
“Output” and enable “Reserved Output” (see pages referring to I/O->Type and I/O->Reserved Output).
Ouput Activation Confirmation: this option is only available for the GS3125 series; tick this box to receive a confirmation ring once
the output has been activated.
CAUTION:
— the ring will be received 1 minute after the output has been activated;
— if the transmitter is already in operation (for example: the GSM channel is busy with a voice communication), the
confirmation ring will not take place;
— the option “Ouput Activation Confirmation” cancels the incoming call after approximately 5 s, even if the “Black
list” option is not enabled.
White List: Enable
or disable
the White List area would allow the Communicator to accept or refuse incoming calls. The
functioning mode of the White List option is linked to the
selection or non-selection
of the Black List, area which is present on
the inside of the Options page->Dial options, as seen in the following table:
White List Black List Functioning mode
Accept incoming calls from any number
Refuse any incoming call
Accept incoming calls only from numbers having an enabled
White List option, refuse call coming from all other numbers
