GS3125/GS3105 23
GG
GG
G
Reserved Output: When this option is selected, all other events selected to activate the corresponding output are ignored. Click the
box corresponding to the output to be activated through caller recognition or via an SMS command. To activate the output using caller
identification, program the telephone number on the “Phonebook” screen and enable the option “Activates output” (see page
Phonebook->Activates output).
Service: A tick
in this column indicates that the Communicator is in its SERVICE status, i.e. when lines 1 and 2 become unbalanced,
instead of making a call, the Communicator will take a specific action independently. An action may be specified for each line, in accordance
with the table below. In any case, if these actions are selected, SMS messages are never sent in reference to inputs 1 and 2.
Input line
no.
Selection Associated Service function
1A
Forced switching on GSM network
2B
Delete telephone queue
CAUTION - These settings also automatically update the parameters on the “SMS dialer”, “Voice dialer” and “Phonebook”
pages.
Control String: In this column, enter the string (maximum 16 alphanumeric characters) to be sent by SMS when you wish to activate/
deactivate the corresponding remote output.
Activation Confirmation: Use this column to select the type of confirmation you want when the output is activated. There are 3 different
options to choose from: None, Ring or SMS (the latter option is not available if the Control string box has been left empty). The output
activation confirmation is forwarded by means of a SMS when the output is activated by SMS.
Table: Programming Effects on Activation Output
PROGRAMMING EFFECTS
Black List White List
Activation
Confirmation
Call
Forwarded
Confirmation
Ring

None YES NO

Ring NO YES

None YES NO

Ring NO YES

None NO NO

Ring NO YES

None YES NO

Ring NO YES
Enabled
Disabled
Monostable: Normally the outputs, when activated, remain so until a deactivation command is received, at which point the output will
revert to its standby status. If you want the output to revert to its standby status automatically after a set amount of time, select this option
and set the activation time using the adjacent Monostable Time (sec) box.
Monostable Time (sec): In this box, enter the value in seconds (from 1 to 86400 in steps of 1 second) indicating the time period for
which the output, if set as Monostable, will remain active before reverting to its standby status (ON Time).
Voice Dialer (GS3125 series only)
This section is used to program all parameters relating to the voice dialer, namely: the telephone numbers to call (the first 8 numbers in the
phonebook), the number of repetitions for each message (minimum 1, maximum 8), the duration and number of the messages in
accordance with the following specifications:
Description: This column lists the events for which a voice message may be programmed.
To select voice messages for the 3 programmable input lines, set the corresponding terminal as an input (see I/O-
>Type).
Telephone numbers: Click the ‘12345678’ columns in accordance with the desired event. The tick
indicates that a particular
telephone number will be called when an event occurs. Click the boxes to enter/remove the tick
.
The telephone numbers are the first 8 entries on the “Phonebook” page.
Voice Message: Triple-click the ‘Message column corresponding to the desired event, then click the button to scroll through the list
of messages (up to 8 messages can be selected, each with a maximum duration of 16 seconds) and select one. Up to 3 voice
messages can be selected for each event (Message#1, Message#2, Message#3).
