DSC LE4000 User Manual

25
Table 16: Network indicator - Digit 3
Domain Name Service (DNS) programming is not permitted in UL/ULC listed systems.
KEYPAD DATA DISPLAY
• Section-Toggle Options: The number is displayed when Toggle is ON. The number is not
displayed when Toggle is OFF. (e.g., Toggle Options displays: “[ -- 3 -- 6 -- ]”. Options 3
and 6 are ON, all others are OFF). Pressing keys 1 through 8 alternately turns the Toggle
ON and OFF.
HEX/Decimal Data: Values that are provided with two defaults, separated by a / character,
use the format: hexadecimal followed by decimal equivalent (e.g., Default [0BF5/3061]).
Hexadecimal numbers are shown, with all leading zeroes,
ENTERING DATA FROM KEYPAD
To enter data at the keypad, press the number key, from the table below, to select the character
that you want. Pressing the number key repeatedly scrolls through the characters available for
that key. Press the [*] key and use
[<] [>] keys to scroll to one of the following selections: (Press
[*] to select the Option).
• ASCII Entry. Use this mode to enter ASCII characters from the keypad.
• Clear to End. This selection clears the remainder of the display.
• Clear Display.This selection completely erases all entries on the display.
• Change Case. Toggles between upper/lower case depending on current selection.
NOTE: The “0” on the keypad is used to delete characters.
Table 16: Data Entry at Keypad
ENTERING ASCII CHARACTERS
To enter American Standard Code for Information Interchange (ASCII) characters at the
keypad, perform the following:
1. Press [*] and use [<] [>] keys to scroll to “ASCII Entry”.
2. Press [*] to select ASCII entry mode.
3. Use the
[<] [>] keys to scroll to the ASCII character you want to use and press [*] to accept.
4. Press [*] to exit ASCII character entry mode and return to normal entry.
NOTE: Authorized access to C24 is required to modify any Cellular Programming section.
Specific panel sections must be configured for proper operation of the Communicator
with the panel.
Network indicator Value Means
OFF No Network Trouble
ON
Radio connection has been restored.
Radio IP failed
Flashing
Incoming transmission
Connect 24 programming
Outgoing transmission
Incoming transmission
GENERAL INFORMATION
Key Value Key Value Key Valu e
1 1-A-B-C 4 4-J-K-L 7 7-S-T-U
2 2-D-E-F 5 5-M-N-O 8 8-V-W-X
3 3-G-H-I 6 6-P-Q-R 9 9-Y-Z-0
