16
[022] Communications Format
Default (04)
Program 03 for Contact ID (CID). Program 04 for SIA. The module can be configured to send
Events in SIA or CID format. The SIA communication format follows the level 2
specifications of the SIA Digital Communication Standard - October 1997. This format sends
the account code along with its data transmission. The transmission looks similar to the
following at the receiver. Example: Nri0 ET001
Where: N = New Event; ri0 = Partition/Area identifier; ET = Panel Absent Trouble; 001 =
Zone 001.
COMMUNICATIONS REPORTING CODES
[023] Panel Absent Trouble
Default (FF)
Program 00 to disable this event or FF to enable. This event occurs when communications
with the panel have been lost for more than 60 seconds.
[024] Panel Absent Trouble Restore
Default (FF)
Program 00 to disable this event or FF to enable. This event occurs when communications
with the control panel have resumed.
[025] Radio Activation Restore
Default (FF)
Program 00 to disable this event or FF to enable. This event occurs after any successful
programming session (using Connect24).
SYSTEM TEST OPTIONS [026 - 029]
Test Transmissions to Primary Receiver, with Backup to Secondary Receiver:
Set Cellular Section [028] to (FF); [029] to (00).
• If the test transmission fails to the primary receiver, it backs up to the secondary receiver.
• If the test transmission fails to the secondary receiver, an FTC trouble is generated.
Test Transmission Unique to Primary and Secondary Receivers:
Set Cellular Section [028] to (FF); [029] to (FF).
• The module sends periodic test transmissions to each receiver independently, with no
backups.
• If the test transmission fails to any of the programmed receivers, an FTC trouble is
generated.
Alternate Test Transmission:
Alternate Test Transmission can be enabled or disabled in section [005], toggle option [7].
[028] Cellular 1 Transmission
Default (FF)
Program 00 to disable this event transmission or FF to enable. See System Test Options
(above) for details on settings.
Table 8: Communications Reporting Codes
Event
SIA
Identifier
SIA
Reporting
Code
CID
Qualifier
CID
Event
Code
CID
Reporting
Code
CID
User/
Zone
[023] Panel Absent Trouble ET 001 1 3 55 001
[024] Panel Absent Trouble
Restore
ER 001 3 3 55 001
[025] Radio Activation Restore RS 001 3 5 52 001
[028] Cellular 1 Test Transmission RP 003 1 6 A3 955
[029] Cellular 2 Test Transmission RP 004 1 6 A3 956
[030] FTC Restore YK 001 3 3 54 001
