HARDWARE COMPATIBILITY
Note for ULC Listed installations:
Products or components of products, which perform communications functions only, must
comply with the requirements applicable to communications equipment as specified in CAN/
CSA –C22.2 No. 60950-1, Information Technology Equipment-Safety - Part 1: General
Requirements. Where network interfaces, such as the following, are internal to the subscriber
control unit or receiver, compliance to CAN/CSA –C22.2 No. 60950-1 is adequate. Such
components include, but are not limited to: Hubs; Routers; Network interface devices; Third
party communications service providers; Digital subscriber line (DSL) modems; and Cable
modems.
Note for UL Listed installations:
Packet switched data network interface equipment, manufactured by other than the burglar
alarm equipment manufacturer, that is not required for the processing of the signals must be
evaluated to the applicable requirements of the Standard for Information Technology
Equipment – Safety – Part 1: General Requirements, UL 60950-1, either as burglar alarm
equipment or communication equipment.
Table 2: LTE Frequency Bands (model LE2077 only)
Band Transmit Band (TX) Receive Band (RX)
LTE B2 1850 MHz to 1910 MHz 1930 MHz to 1990 MHz
LTE B4 1710 MHz to 1755 MHz 2110 MHz to 2155 MHz
LTE B5 824 MHz to 849 MHz 869 MHz to 894 MHz
LTE B12 698 MHz to 716 MHz 728 MHz to 746 MHz
LTE B13 777 MHz to 787 MHz 746 MHz to 756 MHz
UMTS B2 1850 MHz to 1910 MHz 1930 MHz to 1900 MHz
UMTS B5 824 MHz to 840 MHz 824 MHz to 894 MHz
RATINGS
Table 3: Communicator Electrical Ratings
Model
LE2077
Cellular Only
Power Supply Ratings
Input Voltage
3.5 / 3.9 / 4.2 VDC (min / NOM / MAX) from
the SCW9055/SCW9057 panel
Current Consumption 75 mA
Standby Current (@ 3.7V) 75 mA
Alarm (Transmitting) Current) 400 mA @ 3.7V during transmission
Antenna Specifications
Dual band Antenna See Table 1
Environmental Specifications
Operating Temperature 0°C - 49°C (32°F- 120°F)
Humidity 5% ~ 85% relative humidity, non-condensing
Mechanical Specifications
Board Dimensions (mm) 109 x 110
Weight (grams) 60
Table 4: Compatibility
Communicator
Receiver/Control
Panel
Description
LE2077
Receiver
SG System I, v1.14+
SG System II, v2.11+
SG-DRL3-IP, v2.3+
SG-DRL4-IP, v1.2+
SG-DRL5-IP, V1.0+
Control Panel SCW9055/SCW9057 V1.17/1.18
