5.8 Communicator – Reporting Codes
The panel can be programmed to report events to the central
station by sending the Reporting Code programmed for a
particular event.
Reporting codes can be one or two digits and can use Hex
digits (A through F). For a complete description of reporting
codes which can be programmed and lists of automatic Con-
tact ID and SIA format codes, please see Appendix A.
NOTE:Do not use the digit C in a reporting code when using
Pager Format. In most cases, the digit C will be interpreted as
a [#] which will terminate the page before it has finished.
Reporting Codes . . . . . . . . . . . . . . . . . Section [320] to [353]
Cross Zone Police Reporting Code
The Cross Zone Police Code Alarm will be sent when two
different alarms occur during any armed-to-armed period.
When an alarm occurs while the panel is armed and a sec-
ond alarm occurs on a different zone during the same armed
period, or after the system is disarmed, this code will be sent.
All zone types contribute to this alarm. The cross zone police
code will be transmitted immediately unless either or both
zones have the Transmission Delay attribute enabled. If so,
the code will be delayed for the programmed transmission
delay time.
Cross Zone Police Code Alarm . . . . . . . . . . . . Section [328]
Zone Restorals
If the Restoral on Bell Time-out option is selected, the
panel will send the Zone Restoral Reporting Code for the
zone if the bell cut-off time has expired and the zone is
secured. If the zone is not secured when the bell cut-off time
expires, the panel will send the restoral immediately once the
zone is secured, or when the system is disarmed. If the
Restoral on Bell Time-out option is not selected, the panel will
immediately send the Zone Restoral Reporting Code when
the zone is secured, regardless of whether or not the alarm
output is active.
NOTE: 24-hr type zones will report the restoral immediately
when the zone is secured.
Restoral on Bell Time-out . . . . . . . . . . . . . . Section [380]: [2]
Openings/Closings by Wireless Key
If you are using a PC5132 v3.0 or higher, wireless keys with
access codes may be identified when they are used to arm
or disarm the system: the panel will log and transmit opening
or closing by access code (the same as if an access code
had been used to arm/disarm the system). If wireless keys
with no access code are used, the event will be logged and
transmitted as special closing or opening by keyswitch.
The Function Keys Require Code option must be selected
(section [015], option 4 OFF) in order for wireless keys to be
identified for arming. Disarming will always be logged by
access code, if one is programmed for the Key, regardless of
this option.
Wireless Maintenance
The panel will transmit a Wireless Device Low Battery
Alarm reporting code if a low battery condition is indicated
by a detector. Transmission and logging to the event buffer of
the trouble will be delayed by the number of days pro-
grammed for Zone Low Battery Transmission Delay. The
Wireless Device Low Battery Restoral reporting code will
be transmitted when the problem is corrected. The specific
zone that caused the trouble will be recorded in the event
buffer.
NOTE: The restoral will not be transmitted until all detectors
indicate good battery conditions.
Wireless Maintenance Reporting Codes . . . . . Section [353]
Zone Low Battery Transmission Delay . . . . . . . Section [370]
AC Failure Trouble Alarm Code
To prevent the panel from transmitting an AC Failure Trouble
Alarm reporting code during short power outages, the panel
will not send the signal unless AC power is lost for the
amount of minutes programmed for the AC Failure Commu-
nication Delay. The AC Failure Trouble Restoral reporting
code follows the AC failure communication delay as well.
NOTE:If AC Failure Communications Delay is programmed as
“000,” then the AC failure transmission will be immediate.
AC Failure Communication Delay . . . . . . . . . . . Section [370]
5.9 Communicator – Reporting Formats
Each communication telephone number can be programmed
to report using any one of five formats available. Two 20 BPS
pulse formats and two 10bps formats are supported, in addi-
tion to Contact ID, SIA, Pager and Residential Dial formats.
The Communicator Call Direction options can be used to
disable the reporting of events such as Openings and Closings.
NOTE:Do not program the 2nd telephone number to use Con-
tact ID or SIA reporting code formats (section [360]) if Auto-
matic reporting codes are selected for either Contact ID or
SIA (section [381]).
Communicator Format Options. . . . . . . . . . . . . Section [360]
Communicator Call Directions . . . . . . Section [361] to [368]
The following is a description of each reporting format:
Contact ID
Contact ID is a specialized format that will communicate
information using tones rather than pulses. This format allows
more information to be sent faster than other formats. For
example, in addition to reporting an alarm in zone one, the
Contact ID format will also report the type of alarm, such as
an Entry/Exit alarm.
If the Contact ID uses Programmed Reporting Codes
option is enabled, a two digit number from Appendix A must
be entered in programming sections [320] to [353] for each
event to be transmitted. The two digit number determines the
type of alarm. The panel will automatically generate all other
information, including the zone number.
If the Contact ID uses Automatic Reporting Codes option
is enabled, the panel will operate as follows:
1. If an event’s reporting code is programmed as [00], the
panel will not attempt to call the central station.
2. If the reporting code for an event is programmed as any-
thing from [01] to [FF], the panel will automatically gener-
