Program Descriptions: 5.13 Bell
23
TLM Enable/Disable . . . . . . . . . . . . . . . . . . Section [015]: [7]
TLM Trouble Beeps When Armed or
TLM Audible (Bell) When Armed . . . . . . . . Section [015]: [8]
TLM Trouble Reporting Code . . . . . . . . . . . . . . Section [349]
TLM Restoral Reporting Code . . . . . . . . . . . . . Section [350]
TLM Trouble Delay . . . . . . . . . . . . . . . . . . . . . . Section [370]
5.13 Bell
The bell will silence after the number of minutes programmed
for the Bell Cut-off time have passed.
The panel supervises the Bell output. If an open condition is
detected, the panel will immediately indicate a trouble condi-
tion by beeping the keypad twice every 10 seconds to alert
the owner of the problem. The panel can send a Bell Circuit
Trouble and Trouble Restoral reporting codes to indicate the
situation (see section 5.8 “Communicator – Reporting
Codes”).
If Fire Bell Continuous is enabled, the bell will sound until a
code is entered. If disabled, the bell will sound until a code is
entered or the bell cut-off time has expired.
Bell Cut-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . Section [005]
Bell Circuit Trouble Reporting Code. . . . . . . . . Section [349]
Bell Circuit Trouble Restoral Reporting Code. . Section [350]
Fire Bell Continuous . . . . . . . . . . . . . . . . . . . Section [014]:[8]
5.14 Test Transmission
To ensure that the communication link with the central station
is functioning properly, program the panel to send a test trans-
mission signal on a regular basis.
The panel can send a Periodic Test Transmission Report-
ing Code at the programmed Test Transmission Time of
Day. The Test Transmission Cycle determines the period of
time between tests. The option Land Line Test Transmission
in Minutes/Days allows you to select whether the Land Line
Test Transmission cycle will be counted in minutes or days. If
you have selected the test transmission cycle to be in min-
utes, the Test Transmission Time of Day counter will not apply.
NOTE:If you have selected the Land Line Test Transmission in
Minutes option, do not program the test transmission cycle to
be less than 10 minutes.
NOTE: The GSM1000 Test Transmission can only be pro-
grammed in days.
If you program the test transmission cycle for a longer period
of time than it was programmed for previously, the system will
wait the original time period before the next test transmission
is sent, and then begin reporting with the new interval.
The panel can also send a test for the GSM1000 Cellular Com-
municator, if used. If the GSM1000 Test Transmission Code is
programmed, the panel will send a cellular test at the interval
programmed in the GSM1000 Test Transmission Cycle.
Users can also generate a communicator test. If the System
Test Reporting Code is programmed, the panel will send the
signal when the System Test keypad command is entered
(see “[*][6] User Functions”).
Test Transmission Reporting Codes. . . . . . . . . Section [352]
Test Transmission Time of Day . . . . . . . . . . . . . Section [371]
Test Transmission Cycles . . . . . . . . . . . . . . . . . Section [370]
Land Line Test Transmission M/D. . . . . . . . Section [702]: [3]
5.15 Transmission Delay
If the transmission delay zone attribute is selected for a given
zone, the panel will delay reporting an alarm for that zone for
the number of seconds programmed for the Transmission
Delay Time. If the panel is disarmed before the delay time
expires, the panel will not report the event.
Transmission Delay Time . . . . . . . . . . . . . . . . . . Section [370]
5.16 Fire, Auxiliary and Panic Keys
The emergency keys are available on all keypads. These keys
must be pressed and held for two seconds before they will
activate. This two second delay is designed to help prevent
accidental activation.
If the [F] / key option is enabled, when the Fire keys are
pressed and held for two seconds, the panel will activate the
alarm output. The alarm output will sound until a code is
entered or until the bell cut-off time expires. Communication of
the signal to central station is immediate.
If the [A] / key is pressed and held for two seconds, the
panel will sound the keypad beeps three times to verify activa-
tion. The panel will beep the keypad ten times rapidly when a
kissoff is received, to verify communication to the central station.
If the [P] / key is pressed and held for two seconds, the
panel will immediately communicate the signal to central station.
If [P] Key Audible Bell and Buzzer option is enabled, when a
user presses the [P] / key, the keypad will beep three times
and the panel will activate the alarm output until an access
code is entered or the bell cut-off expires. If the option is dis-
abled, the Panic alarm will be completely silent.
Each LCD keypad may be programmed to have the [F], [A], &
[P] keys enabled or disabled. Please refer to Appendix B:
“Programming LCD Keypads”.
NOTE:The Fire, Auxiliary, Panic keys will operate even if Key-
pad Blanking is active (See section 5.22 “Keypad Blanking”).
[F] Key Enable . . . . . . . . . . . . . . . . . . . . . . .Section [015]: [1]
[P] Key Audible Bell and Buzzer . . . . . . . . .Section [015]: [2]
5.17 Arming/Disarming Options
If the Quick Arm option is enabled, the panel can be armed
without an access code by entering [*][0] or by pressing the
Stay or Away function key.
The Quick Exit option, if enabled, will allow someone to leave
an armed premises through a Delay type zone without having
to disarm and re-arm the system. See “[*][0] Quick Exit”.
If the Arm/Disarm Bell Squawk option is enabled, the panel
will squawk the alarm output once upon arming and twice
upon disarming. If an alarm is in memory, when the panel is
disarmed the bell will sound three pairs of disarm squawks.
NOTE: If the panel is armed using the Stay function key, or by
entering [*][9][access code], there will be no bell squawks dur-
ing entry and exit delays, except for the arm/disarm bell
squawks.
Closing Confirmation, if enabled, will cause the keypad to
beep 8 times rapidly after the closing reporting code has
been successfully transmitted to central station.
If the Bypass Status Displayed While Armed option is cho-
sen, the Bypass light will be ON while the system is armed to
indicate that there are bypassed zones.
