Program Descriptions: 5.11 PGM Output Options
21
5.11 PGM Output Options
Programmable outputs PGM1 and PGM2 on the main board
can be programmed by selecting one of the output options
listed below (exceptions noted).
Main Board PGM Outputs . . . . . . . . . . . . . . . . Section [009]
NOTE: PGM outputs cannot be disabled in installer’s program-
ming. To disable a PGM output, you must remove all wiring
from the output.
[01] Burglary and Fire Bell Output
The output will activate when the alarm output is active and
will deactivate when the alarm output is silenced. If the alarm
output is pulsing, the PGM output will pulse as well. This out-
put will follow the activation of the alarm output (pre-alert) for
delayed fire zones.
[02] For Future Use
[03] Sensor Reset ([*][7][2])
NOTE: This output will normally be active (switched to ground).
This option is used to reset power for latching smoke detec-
tors. The output will deactivate for five seconds when the
[*][7][2] command is entered (see “[*][7] Command Output
Functions”). The keypad buzzer will not sound for the five sec-
ond period. After performing a sensor reset, wait 15 seconds
before attempting to arm the system.
Please refer to the Control Panel Wiring Diagram in this man-
ual for wiring instructions.
NOTE: Only ONE of options [03] Sensor Reset and [20] Com-
mand Output Option #2 may be programmed on the same system.
[04] For Future Use
[05] Armed Status
When the system is armed, the PGM output will activate at the
beginning of the exit delay. The output deactivates when the
system is disarmed.
[06] Ready To Arm
The PGM will be active as long as the system is ready to arm
and all non-force armable zones on the system are restored.
Once an access code is entered to arm the system and the
exit delay begins, the PGM output is deactivated.
[07] Keypad Buzzer Follower Mode
The PGM will activate when any of the following events occur
and will remain active for as long as the keypad buzzer is
active:
• Door Chime • Entry Delay
• Auto-arm Prealert • Audible Exit Delay
• 24-hr Supervisory Buzzer Zone
[08] For Future Use
[09] System Trouble Output
The PGM output will activate when any of the selected trouble
conditions are present. It will deactivate when all the selected
trouble conditions are cleared.
The PGM attributes for this option, programmed in sections
[141] to [142], differ from the standard selection of attributes.
Program which trouble conditions will activate the output by
selecting some or all of the following attributes:
Attribute
[1] ..........Service Required (battery, bell, general trouble,
general tamper, general supervisory)
[2] .......... AC Failure
[3] .......... Telephone Line Trouble
[4] ..........Failure to Communicate
[5]...........Fire Trouble / Zone Fault
[6]...........Zone Tamper
[7]...........Zone Low Battery
[8]...........Loss of Clock
[10] System Event (Strobe Output)
The output activates when any of the selected system events
(alarms) occur on the system.
NOTE:This output will activate for silent and audible alarms or
medical conditions only. It will not activate during pre-alert or
delays.
If attribute [8] is turned ON, the output will activate for the
number of seconds programmed in the PGM output timer
(section [164]).
If attribute [8] is turned OFF, in the armed state, the output will
deactivate only once the system is disarmed. If an alarm acti-
vates this output in the disarmed state, the output will deacti-
vate if a user enters a valid access code while the Bell Cut-off
timer is counting down. The output will also deactivate if
someone arms the system after the Bell Cut-off has expired.
This output can be used to indicate that an alarm has
occurred before entering the premises.
The PGM attributes for this option, programmed in Sections
[141] to [142], differ from the standard selection of attributes.
Program which events will activate the output by selecting
some or all of the following attributes:
Attribute
[1] .........Burglary (Delay, Instant, Interior, Stay/Away and
24-hr Burglary Zones)
[2] .........Fire (Fire Keys, Fire Zones)
[3] .........Panic (Panic Keys and Panic Zones)
[4] .........Medical (Auxiliary Keys, Medical and Emergency
Zones)
[5] .........Supervisory (Supervisory, Freezer and Water
Zones)
[6] .........Priority (Gas, Heat, Sprinkler and 24-hr Latching
Zones)
[7] .........Holdup (Holdup zones)
[8] .........Output Follows Timer (output will activate for the
number of seconds programmed in the PGM Out-
put Timer) / Output Latched
NOTE:If attribute [8] is turned ON, attributes [1-7] must also be
turned ON.
PGM Output Timer. . . . . . . . . . . . . . . . . . . . . . . Section [164]
[11] System Tamper (All Sources)
The PGM output will activate when any tamper condition is
present and will deactivate when all tampers are restored.
[12] For Future Use
[13] For Future Use
[14] For Future Use
[15] Remote Operation (DLS-3 Support)
This output can be activated and deactivated remotely using
the DLS software.
[16] GSM1000 Support (PGM1 Only)
The PGM output will be used as a data wire to communicate
telephone number information for the GSM1000 cellular unit.
[17] Away Armed Status
When the system is armed in the Away mode, the PGM output
will activate at the beginning of the exit delay. The output
deactivates when the panel is disarmed.
