Reporting Codes: 5.32 Walk Test (Installer)
43
Table2: Contact ID Zone Alarm/Restoral Event
Codes (as per ADEMCO):
Program any of these codes for zone alarms/restorals when using
the standard (non-automatic) Contact ID reporting format.
Table 3: SIA Format Automatic Zone
Alarm/Restoral Codes
Section # Reporting Code Code Sent When...
Dialer
Direction*
Contact
ID Codes
SIA Auto Rep
Codes**
[349-350] AC Line Trouble/Rest. AC power to control panel is disconnected or inter-
rupted/AC power restored (Both codes follow AC Fail-
ure Comm. Delay.)
MA/R (3) A1 AT-00/AR-00
[349-350] Main Bell Trouble/Rest. open circuit detected across bell terminals/bell circuit
closed
MA/R (3) 21 UT-99/UJ-99
[349-350] Fire Trouble/Rest. a trouble occurs/restores on a fire zone MA/R (3) 73 FT-00/FJ-00
[349-350] Auxiliary Power Trouble/
Rest.
aux voltage supply trouble/restoral MA/R (3) AA YP-00/YQ-00
[350] TLM Restore Telephone line trouble restore MA/R (3) 51 LR-00
[349-350] Gen System Trouble/Rest. “Service Required” trouble occurs (view troubles using
[*][2])/trouble restored
MA/R (3) 33 ET-00/ER-00
[349-350] Gen System Supervisory
Trouble/Rest.
control panel loses/restores communications with mod-
ule(s) connected to the Keybus
MA/R (3) 33 ET-00/ER-00
[351] Line 1 or 2 FTC Restoral control panel has restored communications to central
station on line 1 or 2 (after FTC)
MA/R (3) 54 YK-00
[351] Event Buffer is 75% Full event buffer is almost full since last upload MA/R (6) 23 JL-00
[351] DLS Lead In downloading session start MA/R (4) 11 RB-00
[351] DLS Lead Out downloading session complete MA/R (4) 12 RS-00
[351] Zone Fault/Rest. one or more zones have fault/fault restored MA/R (3) 72 UT-00/UJ-00
[352] Periodic Test periodic system test transmission T (6) A2 RP-00
[352] System Test [*][6] bell/communications test T (6) A1 RX-00
[353] Wireless Device Low Battery
Trouble/Rest.
wireless zones (WLS904, WLS905, WLS907); panic
pendants (WLS908); handheld keypads (WLS910);
wireless keys (WLS909) have low battery/all low batter-
ies restored
MA/R (3) 84 XT-00/XR-00
* A/R = alarms/restorals;T/R = tampers/restorals; O/C = openings/closings; MA/R = miscellaneous alarms/restorals; T = test transmissions
** UU = user number (user01-42); ZZ = zone number (01-08)
Medical Alarms (1)34 Entry / Exit
(1)AA Medical (1)35 Day / Night
(1)A1 Pendant Transmitter (1)36 Outdoor
(1)A2 Fail to Report In (1)37 Tamper
Fire Alarms (1)38 Near Alarm
(1)1A Fire Alarm General Alarms
(1)11 Smoke (1)4A General Alarm
(1)12 Combustion (1)43 Exp. module failure
(1)13 Water Flow (1)44 Sensor tamper
(1)14 Heat (1)45 Module Tamper
(1)15 Pull Station
(1)4A Cross Zone Police Code
(1)16 Duct 24-hr Non-Burglary
(1)17 Flame (1)5A 24-hr non-Burg
(1)18 Near Alarm (1)51 Gas detected
Panic Alarms (1)52 Refrigeration
(1)2A Panic (1)53 Loss of Heat
(1)21 Duress (1)54 Water Leakage
(1)22 Silent (1)55 Foil Break
(1)23 Audible (1)56 Day Trouble
Burglar Alarms (1)57 Low bottled Gas level
(1)3A Burglary (1)58 High Temp
(1)31 Perimeter (1)59 Low Temp
(1)32 Interior (1)61 Loss of Air Flow
(1)33 24-hr
Zone Definition
SIA Auto Rep
Codes*
Zone Alm/Rest.
Delay, Instant, Interior, Delay
Stay/Away, Interior Stay/Away,
24-hr Burg.
BA-ZZ/BH-ZZ
Standard 24-hr Fire, Delayed 24-
hr Fire
FA-ZZ/FH-ZZ
24-hr Supervisory US-ZZ/UR-ZZ
24-hr Supervisory Buzzer UA-ZZ/UH-ZZ
24-hr Sprinkler SA-ZZ/SH-ZZ
24-hr Gas GA-ZZ/GH-ZZ
24-hr Heat KA-ZZ/KH-ZZ
24-hr Medical MA-ZZ/MH-ZZ
24-hr Emergency (non-medical) QA-ZZ/QH-ZZ
24-hr Waterflow WA-ZZ/WH-ZZ
24-hr Freeze ZA-ZZ/ZH-ZZ
24-hr Holdup HA-ZZ/HH-ZZ
24-hr Panic PA-ZZ/PH-ZZ
Latching 24-hr, 24-Hr Bell/
Buzzer
BA-ZZ/BH-ZZ
* ZZ = zones 01-08
