DSE DSE4610 - Outputs

Specification
15
3.8.4 MAGNETIC PICKUP
Type Single ended input, capacitive coupled
Minimum Voltage 0.5V RMS
Max Common Mode Voltage ±2V
Maximum Voltage Clamped to ±70V by transient suppressers, dissipation not to
exceed 1W.
Maximum Frequency 10,000Hz
Resolution 6.25 RPM
Accuracy ±25 RPM
Flywheel Teeth 10 to 500
3.9 OUTPUTS
3.9.1 DC OUTPUTS A & B (FUEL & START)
Type Fixed for use as Fuel and Start output control.
Rating 10A resistive for 10secs, 5A resistive continuous at 35V
3.9.2 CONFIGURABLE DC OUTPUTS C & D
Type Fully configurable, supplied from DC supply terminal 2.
Rating 2A resistive continuous at 35V
3.9.3 CONFIGURABLE DC OUTPUTS E & F (DSE4620 ONLY)
Type Fully configurable, supplied from DC supply terminal 2.
Rating 2A resistive continuous at 35V
