Maintenance, Spares, Repairs and Servicing
84
10 MAINTENANCE, SPARES, REPAIR AND SERVICING
The controller is Fit and Forget. As such, there are no user serviceable parts within the controller.
In the case of malfunction, you should contact your original equipment manufacturer (OEM).
10.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE
If you require additional plugs from DSE, please contact our Sales department using the part
numbers below.
10.1.1 PACK OF PLUGS
Module Type Plug Pack Part Number
4610-01 100-400-41
4620-01 100-400-42
4610-02, 4610-03 & 4610-04 100-400-47
4620-02, 4620-03 & 4620-04 100-400-46
10.1.2 INDIVIDUAL PLUGS
Module Terminal Designation Plug Description Part No.
1-9
DSE4620 Only
9 way 5.08mm 007-166
1-7
DSE4610 Only
7 way 5.08mm 007-155
10-20 11 way 5.08mm 007-451
21-24 4 way 10.16mm 007-003
25-28
DSE4620 Only
4 way 10.16mm 007-003
29-32
Not fitted on 46xx-01
4 way 5.08mm 007-282
PC Configuration interface lead
(USB type A – USB type B)
016-125
10.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE
Item Description Part No.
Module Fixing Clips (Packet Of 2) 020-406
10.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE
Item Description Part No.
Module Silicon Sealing Gasket 020-282
